Cable Pulling Winch CT-2MAX

What is the advantage of CT-2max electrical cable pulling & laying machine？

• + Adopts high quality pure copper core motor
• + Four gears of infinitely variable speed with start and stop, push and pull a key to switch
• + The whole system is equipped with a joint control module, which can be used by more than one joint control
• + Nylon pressure wheel with high-quality rubber wheel carefully designed, long service life
• + Panel+remote control+multi-sets of joint control Multiple modes, flexible choice

Parameters

Power Supply:AC380V (standard)

Speed Adjustment:4 levels + stepless speed regulation

Power:3000W (AC)

Conveying Speed:4 – 26m/min

Optimal Speed:16 – 26m/min (2nd and 3rd gears)

Maximum Pulling Force:6000N

Cable Diameter:1 – 18cm

Dimensions:90X53X67cm

Net Weight:126kg
